H3C WA6320S-E Indoor Ceiling-mounted 802.11ax Wireless Access Point

H3C WA6320S-E Indoor Ceiling-mounted 802.11ax Wireless Access Point
H3C WA6320S-E Indoor Ceiling-mounted 802.11ax Wireless Access Point

Large Image :  H3C WA6320S-E Indoor Ceiling-mounted 802.11ax Wireless Access Point

Product Details:
Brand Name: H3C
Model Number: WA6320S-E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $140-300
Contact Now

H3C WA6320S-E Indoor Ceiling-mounted 802.11ax Wireless Access Point

Description
Attribute: WA6320S-E Dimensions: 130mm × 130mm × 36mm
PoE: Supports 802.3af Compatible Power Supply Console Port: 1
Operating Frequency Band: 802.11ax/b/g/n: 2.4GHz-2.483GHz (China) Modulation Scheme: 11ax: MIMO-OFDM: BPSK,QPSK
Highlight:

H3C WA6320S-E wireless access point

,

802.11ax ceiling-mounted access point

,

indoor WiFi 6 access point


H3C WA6320S-E Indoor Desktop-type 802.11ax Wireless Access Point


Product Overview

As a new-generation self-developed 802.11ax AP by H3C, WA6320S-E adopts dual-band four-stream design and suits enterprises, campuses, medical facilities and other scenarios. Equipped with smart built-in antennas and dual-band access, it features compact outlook and flexible installation including wall mounting, ceiling mounting and 86-type box mounting.


Attribute WA6320S-E
Dimensions (excluding antenna interface and accessories, L×W×H) 130mm × 130mm × 36mm
Ethernet Interface 1 × 10/100/1000Mbps electrical port
PoE Supports 802.3af compatible power supply
Local Power Supply Supports 54V DC
Console Port 1
Built-in Antenna Built-in smart antenna system
Operating Frequency Band 802.11ax/ac/n/a: 5.725GHz-5.850GHz (China);
5.47GHz~5.725GHz; 5.15GHz~5.35GHz (China)
802.11ax/b/g/n: 2.4GHz-2.483GHz (China)
Modulation Technology MIMO-OFDM (11n): MCS 0-15
MIMO-OFDM (11ac): MCS 0-9
MIMO-OFDM (11ax): MCS 0-11
Modulation Scheme 11n:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM
11ac/ac wave2:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM
11ax: MIMO-OFDM: BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM
Transmit Power 23dBm
Adjustable Power Granularity 1dBm
Reset / Restore Factory Configuration Supported
Status Indicator Blink alternate flashing mode, yellow/green/blue different working status flashing modes, terminal access breathing flashing mode
Operating / Storage Temperature -10°C ~ 55°C / -40°C ~ 70°C
Operating / Storage Humidity 5% ~ 95% (Non-condensing)
Power Consumption ≤10.8W
Safety Standards GB4943, EN/IEC/UL 60950-1, EN/IEC/UL 62368-1
EMC EN 55024, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 301 489-1, EN 301 489-17, EN60601-1-2
Environmental Standards GB/T 2423, GB/T 13543, GB 4208
RF Certification FCC Part 15, EN 300 328, EN 301 893, MIIT Radio Transmission Equipment Type Approval
Health Standard EN 50385
MTBF > 850000H



Product Features


Leading 802.11ax Technology

Adopting mature 802.11ax standard with dual-band three-stream design, it delivers a total rate of 1.175Gbps, enabling cloud access and lower total cost of ownership (TCO) via superior coverage, high access density and stable operation.

Key Wi-Fi 6 Technologies

  • OFDMA: Divides bandwidth into subcarriers for concurrent multi-user transmission, reducing latency and optimizing experience for voice and video services.
  • Spatial Reuse: Mitigates co-channel interference and improves spectrum utilization by adjusting transmit power.
  • TWT: Schedules terminal sleep and wake-up cycles to cut collisions and power consumption.


Energy-saving Design

It supports Dynamic MIMO Power Save, Enhanced APSD and Green AP mode for precise power control. Innovative Per-Packet Power Control dynamically adjusts bidirectional power to reduce device power use and extend terminal battery life.


Local Forwarding

In Fit AP mode, it supports local data forwarding instead of transmitting all traffic to remote controllers, greatly saving WAN bandwidth.


IPv4/IPv6 Dual Stack

Fully supports Native IPv6. It can automatically register with H3C WX series controllers regardless of wired network types, achieving seamless network integration.


EAD Wireless Access

The End user Admission Domination solution enforces enterprise security policies. It isolates or restricts risky terminals to safeguard overall wireless network security.


Remote Probe Analysis

Works as a sensor to capture and mirror Wi-Fi packets for troubleshooting and optimization. It supports dedicated working channel mirroring and full-channel polling to meet O&M demands.


Built-in RF Optimizing Engine (ROE)

Boosts performance in high-density access and media streaming via multi-user scheduling, interference filtering, spectrum navigation, multicast enhancement, per-packet power control and bandwidth guarantee.


Intelligent Load Balancing

It balances users and traffic only within overlapping coverage areas to avoid misjudgment, maximizing overall wireless network capacity.


Chinese SSID Support

Supports SSIDs with up to 16 Chinese characters or mixed Chinese and English for local use convenience.


Integrated Wired & Wireless Management

Compatible with H3C WSM based on iMC platform. This web-based management system realizes unified management of device status, faults, performance, firmware, configurations and access users, delivering full-featured wired and wireless integrated management.
