Product Details:
|
| Attribute: | S1750-24G-HPWR | Packet Forwarding Rate: | 72Mpps |
|---|---|---|---|
| Electrical Port Attributes: | Support MDI/MDI-X | IPv4 Features: | DHCP Client |
| Management Features: | Support DNS CLINET | Operating & Storage Humidity: | Operating: 5~95%RH, Non-condensing |
| Highlight: | H3C S1750 lightly managed switch,24-port Gigabit switch with HPWR,H3C S1750 fibre channel switch |
||
| Specifications | |
| Attribute | S1750-24G-HPWR |
| Switching Capacity | 128Gbps |
| Packet Forwarding Rate | 72Mpps |
| Fixed Ports | 24×10/100/1000 BASE-T PoE+ Ethernet ports |
| Electrical Port Attributes | Support half-duplex, full-duplex, auto-negotiation mode Support MDI/MDI-X |
| Ethernet Functions | Static MAC configuration Support MAC address learning limit (MAC address depth up to 8K) |
| IPv4 Features | DHCP Client |
| Security Features | Support port security Support black hole MAC |
| Management Features | Support LiteWare-based WEB interface light management Support DNS CLINET |
| Operating Temperature | -5℃ ~ 45℃ |
| Operating & Storage Humidity | Operating: 5~95%RH, non-condensing Storage: 5~95%RH, non-condensing |
| Lightning Protection Level | |
| PoE Capability | Support PoE+, maximum output power per port 30W |
| Power Consumption | MIN: AC 8W MAX: AC 410W (PoE 370W) |
| Weight (Fully Configured) | ≤ 3.5kg |
| Input Voltage | AC 180-264V |
| Dimensions (L×W×H, mm) | 440×230×43.6 |
| Cooling Method | 2 independent fan frames, two-level speed adjustment |
