Product Details:
Brand Name: HUAWEI
Model Number: 2488HV5
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $1990-4199 pcs Negotiable
Packaging Details: 50/pcs/week
Supply Ability: 1-100

48 DDR4 DIMMs 2u rackmount server Huawei 2488h V5

Description
Model: FusionServer 2488HV5 Processors: One Or Two 3rd Gen Intel® Xeon® Scalable Ice Lake Processors (8300/6300/5300/4300 Series), Thermal Design Power (TDP) Up
Memory: 48 DDR4 DIMM Slots, 2,933 MT/s; Up To 24 Intel® Optane™ PMem Modules (100 Series), 2666 MT/s Local Storage: Supports Various Drive Configurations And Hot Swappable: • 10 X 2.5-inch Drives (6–10 NVMe SSDs And 0–4 SAS/SATA Drives, With A Total Number Of 10 Or Less) • 10 X 2.5-inch Drives (2–4 NVMe SSDs And 6–8 SAS/SATA Drives, With A Total Number Of 10 Or Less) •
RAID Support: Supports RAID 0, 1, 10, 5, 50, 6, Or 60, Optional Supercapacitor For Cache Data Power Failure Protection, RAID Level Migration, Power Supply: • 900 W AC Platinum/Titanium PSUs (input: 100 V To 240 V AC, Or 192 V To 288 V DC) • 1500 W AC Platinum PSUs 1000 W (input: 100 V To 127 V AC) 1500 W (input: 200 V To 240 V AC, Or 192 V To 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V To 400 V DC) • 120
High Light:

48 DDR4 DIMMs 2u Rackmount Server

,

2u Rackmount Server HUAWEI 2488H

,

2u Rackmount Server Huawei 2488h V5

Original Huawei 2488H V5 Intel Xeon 2U Rack Server Supp Huawei 2488H V5 Intel Xeon 2U RackServer Suppor



Product Introduction

The FusionServer 2488H V5 is a 2U, 4-socket rack server, ideal for virtualization, HPC, database, and SAP HANA. In a virtualization application, one FusionServer 2488H V5 reduces OPEX by about 32 percent compared with two traditional 2U, 2S rack servers. The 2488H V5 supports 4 Intel® Xeon® Scalable processors in a 2U space, up to 48 DDR4 DIMMs, and up to 25 x 2.5-inch hard drives for local storage (configurable with 8 NVMe SSDs). It incorporates patented technologies, such as Dynamic Energy Management Technology (DEMT) and Fault Diagnosis & Management (FDM), and integrates FusionDirector software for entire-lifecycle management, helping customers drive down OPEX and improve Return On Investment (ROI). * Source: Test results from Global Computing Innovation OpenLab, Q2 2017.



48 DDR4 DIMMs 2u rackmount server Huawei 2488h V5 0

48 DDR4 DIMMs 2u rackmount server Huawei 2488h V5 1





Technical Specifications



Specification Name Specifications
Model FusionServer 2488H V5
Form Factor 2U rack server
Processors

2 or 4 1st Generation Intel® Xeon® Scalable processors (5100/6100/8100 series), up to 205 W

2 or 4 2nd Generation Intel® Xeon® Scalable processors (5200/6200/8200 series), up to 205 W

Memory 48 DDR4 DIMM slots, 2,933 MT/s; up to 24 Intel® Optane™ PMem modules (100 series), 2666 MT/s
Internal Storage

Supports the following hard drive configuration options:

8 x 2.5-inch SAS/SATA HDDs on the front

25 x 2.5-inch SAS/SATA HDDs on the front

24 x 2.5-inch SAS/SATA HDDs on the front

8 x 2.5-inch NVMe SSDs and 16 x 2.5-inch SAS/SATA HDDs on the front

24 x 2.5-inch NVMe SSDs

Supports flash storage: 2 M.2 SSDs

RAID Support

Supports RAID 0, 1, 5, 6, 10, 50, or 60

Supports a supercapacitor for cache power-off protection

Supports functions such as RAID level migration, drive roaming

LOM Network Ports 2 x GE + 2 x 10 GE ports
PCIe Expansion Up to 11 PCIe 3.0 slots
Fan Modules 4 hot-swappable fan modules with optional N+1 redundancy
Power Supply Units

hot-swappable PSUs, with support for 1+1 redundancy. The following PSUs are supported:

2,000W AC Platinum PSUs

1,500W AC Platinum PSUs

900W AC Platinum PSUs

1,200W DC PSUs

Management

iBMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening

iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management

(Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management

Operating Temperature 5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A3 and A4
Certifications CE, UL, FCC, CCC, and RoHS
Installation Suite L-shaped guide rails, adjustable guide rails, and holding rails
Dimensions (H x W x D) 86.1 mm (2U) x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.)

Notices:

1. Open the packaging, check the products carefully, and take them gently.
2. The product is a brand new original unopened equipment.
3. All products 3 year warranty, and the buyer is responsible for the return shipping cost.

International Buyers Please Note:
Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility.
Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying.
Customs fees are normally charged by the shipping company or collected when you pick the item up. These fees are not additional shipping charges.
We won't under-value merchandise or mark the item as a gift on customs forms. Doing that is against U.S. and international laws.
Customs delays are not the responsibility of the seller.
