1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U

1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U
1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U 1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U 1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U 1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U

Large Image :  1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U

Product Details:
Brand Name: HUAWEI
Model Number: 1288HV6
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $189-3799 pcs Negotiable
Packaging Details: 100/pcs/week
Supply Ability: 1-100

1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U

Description
Model: FusionServer 1288H V6 Processors: One Or Two 3rd Gen Intel® Xeon® Scalable Ice Lake Processors (8300/6300/5300/4300 Series), Thermal Design Power (TDP) Up
Memory: 32 DDR4 DIMMs, Up To 3,200 MT/s; 16 Optane™ PMem 200 Series, Up To 3,200 MT/s Local Storage: Supports Various Drive Configurations And Hot Swappable: • 10 X 2.5-inch Drives (6–10 NVMe SSDs And 0–4 SAS/SATA Drives, With A Total Number Of 10 Or Less) • 10 X 2.5-inch Drives (2–4 NVMe SSDs And 6–8 SAS/SATA Drives, With A Total Number Of 10 Or Less) •
RAID Support: Supports RAID 0, 1, 10, 5, 50, 6, Or 60, Optional Supercapacitor For Cache Data Power Failure Protection, RAID Level Migration, Power Supply: • 900 W AC Platinum/Titanium PSUs (input: 100 V To 240 V AC, Or 192 V To 288 V DC) • 1500 W AC Platinum PSUs 1000 W (input: 100 V To 127 V AC) 1500 W (input: 200 V To 240 V AC, Or 192 V To 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V To 400 V DC) • 120
High Light:

1288H V6 Huawei Fusionserver

,

32 DDR4 Huawei Fusionserver

,

1U Fusionserver 1288h V6

FusionServer 1288H V6 (1288H V6)



The FusionServer 1288H V6 is a 1U 2-socket rack server. It improves space utilization for data centers and is ideal for high-density deployment scenarios for workloads such as cloud computing, virtualization, high-performance computing (HPC), and big data processing. The 1288H V6 is configured with two Intel® Xeon® Scalable processors and provides up to 32 DDR4 DIMMs, and 4 x 3.5-inch or 10 x 2.5-inch local storage resources (configurable with 4 or 10 NVMe SSDs). It incorporates patented technologies, such as Dynamic Energy Management Technology (DEMT) and Fault Diagnosis & Management (FDM), and integrates FusionDirector software for entire-lifecycle management, helping customers drive down operating expense (OPEX) and improve return on investment (ROI).



1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U 0

1288H V6 Huawei Fusionserver Supports 32 DDR4 DIMM And 10 2.5 Inch Hard Disk 1U 1







Technical Specifications

Specification Name Specifications
Model FusionServer 1288H V6
Form Factor 1U rack server
Processors One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), thermal design power (TDP) up to 270 W
Chipset Intel C621A
Memory 32 DDR4 DIMMs, up to 3,200 MT/s; 16 Optane™ PMem 200 series, up to 3,200 MT/s
Local Storage

Supports various drive configurations and hot swappable:

• 10 x 2.5-inch drives (6–10 NVMe SSDs and 0–4 SAS/SATA drives, with a total number of 10 or less)

• 10 x 2.5-inch drives (2–4 NVMe SSDs and 6–8 SAS/SATA drives, with a total number of 10 or less)

• 10 x 2.5-inch SAS/SATA/SSD drives

• 8 x 2.5-inch SAS/SATA/SSD drives

• 4 x 3.5-inch SAS/SATA/SSD drives

Supports flash storage:

• Dual M.2 SSDs

RAID Support Supports RAID 0, 1, 10, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
Network

Provides expansion capability of multiple types of networks

Provides the OCP 3.0 network adapter. The two FlexIO card slots support two OCP 3.0 network adapter respectively, which can be configured as required

Hot swappable function supported

PCIe Expansion Provides six PCIe slots, including one PCIe slot dedicated for RAID card, two FlexIO card slots dedicated for OCP 3.0 network adapters, and three PCIe 4.0 slots for standard PCIe cards
Fan Modules Seven hot-swappable counter-rotating fan modules in N+1 redundancy mode
Power Supply

Two hot-swappable PSUs in 1+1 redundancy mode. Supported options include:

• 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)

• 1500 W AC Platinum PSUs

1000 W (input: 100 V to 127 V AC)

1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC)

• 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC)

• 1200 W -48 V to -60 V DC PSUs (input: -38.4 V to -72 V DC)

• 2000 W AC Platinum PSUs

1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)

2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)

Management

The iBMC chip integrates one dedicated Gigabit Ethernet (GE) management port to provide comprehensive management functions such as fault diagnosis, automated O&M, and hardware security hardening

• The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports CD-free deployment and Agentless for smart and simplified management

• (Optional) Configured with the FusionDirector management software to provide advanced management functions such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling automatic management throughout the lifecycle

Operating Systems Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, etc
Security Features Supports power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and cover opening detection
Operating Temperature 5°C to 45°C (41°F to 113°F) (ASHRAE Classes A1 to A4 compliant)
Certifications CE, UL, FCC, CCC, VCCI, RoHS, etc
Installation Kit Supports L-shaped guide rails, adjustable guide rails, and holding rails
Dimensions (H x W x D)

Chassis with 3.5-inch drives: 43.5 mm x 447 mm x 790 mm

Chassis with 2.5-inch drives: 43.5 mm x 447 mm x 790 mm



Notices:

1. Open the packaging, check the products carefully, and take them gently.
2. The product is a brand new original unopened equipment.
3. All products 3 year warranty, and the buyer is responsible for the return shipping cost.

International Buyers Please Note:
Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility.
Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying.
Customs fees are normally charged by the shipping company or collected when you pick the item up. These fees are not additional shipping charges.
We won't under-value merchandise or mark the item as a gift on customs forms. Doing that is against U.S. and international laws.
Customs delays are not the responsibility of the seller.
