Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount

Certification
China Beijing Qianxing Jietong Technology Co., Ltd. certification
China Beijing Qianxing Jietong Technology Co., Ltd. certification
Customer Reviews
The sales staff of Beijing Qianxing Jietong Technology Co.,Ltd are very professional and patient. They can provide quotations quickly. The quality and packaging of the products are also very good. Our cooperation is very smooth.

—— 《Festfing DV》LLC

When I was looking for intel CPU and Toshiba SSD urgently, Sandy from Beijing Qianxing Jietong Technology Co., Ltd gave me a lot of help and got me the products I needed quickly. I really appreciate her.

—— Kitty Yen

Sandy of Beijing Qianxing Jietong Technology Co.,Ltd is a very careful salesman, who can remind me of configuration errors in time when I buy a server. The engineers are also very professional and can quickly complete the testing process.

—— Strelkin Mikhail Vladimirovich

I'm Online Chat Now

Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount

Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount
Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount

Large Image :  Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount

Product Details:
Place of Origin: China
Brand Name: DELL EMC
Model Number: PowerEdge R6525 Rack Server
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $2460-5150 pcs Negotiable
Packaging Details: Carton Packaging
Delivery Time: 5-8 working days
Payment Terms: T/T
Supply Ability: 50/pcs/week

Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount

Description
Processor: Up To Two 2nd Or 3rd Generation AMD EPYCTM Processors With Up To 64 Cores Per Processor Memory Module Slots: 32 DDR4 RDIMM Slots
Front Bays: Up To 4 X 3.5” Hot Plug SAS/SATA (HDD) Internal Controllers: PERC HBA345, H345, H745
External Controllers: H840, 12Gbps SAS HBA Slots PCIe: 3 X Gen4 Slots (x16) At 16GT/s
High Light:

Custom Storage Server 32GB DDR4 EMC

,

Custom Storage 32GB DDR4 R6525

,

Custom Storage Server DDR4 EMC

Hot selling Dells 1U PowerEdge Rack server R6525 AMD EPYC Factory customization storage servers HPC, dense VDI

Dell EMC PowerEdge R6525



Ideal for High Performance Dense-Computing environments


The Dell EMC PowerEdge R6525 Rack Server is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovations for dense compute environments to address traditional and emerging workloads and applications.


Deliver breakthrough performance, innovation and density for traditional and emerging workloads
The new Dell EMC PowerEdge R6525 is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovation for dense compute environments. It’s ideal for traditional and emerging workloads and applications. High-level features include:
• 64 processing cores and faster data transfer speeds with PCIe Gen 4
• Up to 3200MT/s memory speed to reduce latency and deliver faster response
• Multi GPU support to accelerate end user VDI performance
• Highest core count PE 1U server with cryptographic isolation between hypervisor and VMs



Increase efficiency and accelerate operations with an automated infrastructure
The Dell EMC OpenManage™ systems management portfolio delivers an efficient and comprehensive solution for PowerEdge servers through tailored, automated, and repeatable processes.
• Automate server life cycle management with scripting via the iDRAC Restful API with Redfish conformance.
• Simplify and centralize one to many management with the OpenManage Enterprise console.
• Utilize the OpenManage Mobile app and PowerEdge Quick Sync 2 to easily manage servers using a phone or tablet.
• Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus and SupportAssist.



Fortify your data center with integrated security
Every PowerEdge server is designed with a cyber resilient architecture, integrating security deeply into every phase in the lifecycle, from design to retirement.
• Enhance security with platform enablement of AMD Secure Memory Encryption (SME) and Secure Encrypted Virtualization (SEV).
• Operate your workloads on a secure platform anchored by cryptographically trusted booting and silicon root of trust.
• Maintain server firmware safety with digitally signed firmware packages.
• Detect and remediate unauthorized or malicious change with drift detection and system lockdown.
• Securely and quickly wipe all data from storage media including hard drives, SSDs and system memory with System Erase.



PowerEdge R6525
The PowerEdge R6525 provides a unique dense – 1U, dual-socket server - to address and scale traditional and emerging workloads like
• High Performance Computing (HPC)
• Virtual Desktop Infrastructure (VDI)
• Virtualization



PowerEdge R6525
Features Technical Specification
Processor Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor
Memory Up to 32 x DDR4
Maximum RAM
RDIMM 2 TB
LRDIMM 4TB Max
Bandwidth up to 3200 MT/S
Availability Hot plug redundant Hard drives, Fans, PSUs
Controllers PERC 10.5 – HBA345, H345, H745, H840, 12G SAS HBA
PERC 11 – H755, H755N
Chipset SATA/SW RAID (S150): Yes
Drive Bays Front Bays
Up to 4 x 3.5” hot plug SAS/SATA (HDD)
Up to 8 x 2.5” hot plug SAS/SATA (HDD)
Up to 12 x 2.5” (10 Front + 2 Rear)
hot plug SAS/SATA/NVMe
Optional Internal: 2 x M.2 (BOSS)
Optional Rear: 2 x M.2 (BOSS-S2)
Power Supplies 800W Platinum
1400W Platinum
1100W Titanium
Fans Hot plug Fans
Dimensions Height: 42.8mm (1.7”)
Width: 434.0mm (17.1”)
Depth: 736.54mm (29”)
Weight: 21.8kg (48.06lbs)
Rack Units 1U Rack Server
Embedded mgmt iDRAC9
iDRAC RESTful API with Redfish
iDRAC Direct
Quick Sync 2 BLE/wireless module
Bezel Optional LCD bezel or security bezel
OpenManage™ SW OpenManage Enterprise
OpenManage Enterprise Power Manager
OpenManage Mobile
Integrations &
Connections
OpenManage Integrations
BMC Truesight
Microsoft® System Center
Redhat® Ansible® Modules
VMware® vCenter™
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI
Security Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown
TPM 1.2/2.0, TCM 2.0 optional
Embedded NIC 2 x 1 GbE LOM ports
Networking Options (NOC) OCP x16 Mezz 3.0 + 2 x 1GE LOM
GPU Options Up to 2 Single-Wide GPU
Ports Front Ports:
1 x Dedicated iDRAC direct micro-USB
1 x USB 2.0
1 x VGA
Rear Ports:
1 x Dedicated iDRAC network port
1 x Serial (optional)
1 x USB 3.0
1 x VGA
PCIe 3 x Gen4 slots (x16) at 16GT/s
Operating Systems &
Hypervisors
Canonical® Ubuntu® Server LTS
Citrix® HypervisorTM
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®





Chassis views and features
Front view of the system
Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 0

Figure 1. Front view of the 10 x 2.5-inch drive system
1. Left control panel
2. VGA port
3. Right control panel
4. Information tag
5. Drive (10)
Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 1

Figure 2. Front view of the 8 x 2.5-inch drive system
1. Left control panel

2. Drive (8)
3. Right control panel

4. VGA port
5. Information tag



Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 2

Figure 3. Front view of the 4 x 3.5-inch drive system
1. Left control panel
2. Drive (4)
3. VGA port
4. Right control panel
5. Information tag


Rear view of the system

Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 3

Figure 4. Rear view of the 10 x 2.5-inch drive system
1. Power supply unit (PSU 1)
2. PCIe expansion card riser (slot 1)
3. PCIe expansion card riser (slot 2)
4. USB 2.0 port (1)
5. Power supply unit (PSU 2)
6. VGA port
7. USB 3.0 port (1)
8. iDRAC dedicated port
9. System identification button
10. OCP NIC port (optional)
11. NIC port (2)
12. BOSS S2 card (optional)
Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 4

Figure 5. Rear view of the 8 x 2.5-inch drive system.
1. Power supply unit (PSU 1)
2. PCIe expansion card riser (slot 1)
3. PCIe expansion card riser (slot 2)
4. USB 2.0 port (1)
5. PCIe expansion card riser (slot 3)
6. Power supply unit (PSU 2)
7. VGA port
8. USB 3.0 port (1)
9. iDRAC dedicated port
10. System identification button
11. OCP NIC port (optional)
12. NIC port (2)
13. BOSS S2 card (optional)
Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 5

Figure 6. Rear view of the 4 x 3.5-inch drive system with 2 x 2.5-inch rear drive module
1. Power supply unit (PSU 1)
2. Rear drive module
3. USB 2.0 port (1)
4. PCIe expansion card riser (slot 3)
5. Power supply unit (PSU 2)
6. VGA port
7. USB 3.0 port (1)
8. iDRAC dedicated port
9. System identification button
10. OCP NIC port (optional)
11. NIC port (2)
12. BOSS S2 card (optional)



Inside the system
Custom Storage Server 32GB DDR4 Dell EMC PowerEdge R6525 1U Rack Mount 6

Figure 7. Inside the system
1. Drive backplane

2. Rear mounting front PERC module
3. Dual fan module (4)

4. System board
5. Memory DIMM socket for processor 2 (B1)

6. Heat sink for processor 2
7. Riser 3 8. Intrusion switch
9. Power supply unit (PSU 2)

10. Power supply unit (PSU 1)

11. IDSDM/Internal USB card port

12. BOSS slot
13. Riser 2

14. Heat sink for processor 1
15. Memory DIMM socket for processor 1 (A1)

16. xGMI cables
