IronWolf Pro is designed for commercial and enterprise NAS. Delivering Tough, Ready and Scalable 24x7 performance in multibay, multi-user environments.
| Specifications |
30TB |
28TB |
| Standard Model Number |
ST30000NT011 |
ST28000NT000 |
| Interface |
SATA 6Gb/s |
SATA 6Gb/s |
| Features |
| Drive Bays Supported |
Unlimited |
Unlimited |
| Recording Technology |
CMR |
CMR |
| Drive Design (Air or Helium) |
Helium |
Helium |
| Workload Rate Limit (WRL) |
550 |
550 |
| Rotational Vibration (RV) Sensors |
Yes |
Yes |
| Cache (MB) |
512MB |
512MB |
| Reliability/Data Integrity |
| Mean Time Between Failures (MTBF, hours) |
2500000hr |
2500000hr |
| Nonrecoverable Read Errors per Bits Read, Max |
1 per 10E15 |
1 per 10E15 |
| Power-On Hours (per year) |
8,760 |
8,760 |
| Sector Size (Bytes per Logical Sector) |
512E |
512E |
| Rescue Data Recovery Services(years) |
3 |
3 |
| Limited Warranty (years) |
5 |
5 |
| Performance |
| Spindle Speed (RPM) |
7200RPM |
7200RPM |
| Interface Access Speed (Gb/s) |
6.0,3.0,1.5 |
6.0,3.0,1.5 |
| Max. Sustained Transfer Rate OD (MB/s) |
275 |
270 |
| Rotational Vibration @ 10-1500 Hz (rad/s) |
12.5 |
12.5 |
| Power Consumption |
| Startup Current, Typical (12V, A) |
2.0A |
2.0A |
| Idle Power, Average (W) |
6.8W |
6.8W |
| Average Operating Power (W) |
8.3W |
8.3W |
| Standby Mode, Typical (W) |
1.2W |
1.2W |
| Sleep Mode, Typical (W) |
1.2W |
1.2W |
| Power Supply Requirements |
+12V and +5 V |
+12V and +5 V |
| Environmental/Temperature |
| Operating Temperature (ambient, min °C) |
10°C |
10°C |
| Operating Temperature (drive reported, max °C) |
60°C |
60°C |
| Nonoperating Temperature (ambient, min °C) |
-40°C |
-40°C |
| Nonoperating Temperature (ambient, max °C) |
70°C |
70°C |
| Environmental/Acoustics |
| Vibration, Nonoperating: 10Hz to 500Hz (Grms) |
2.27 |
2.27 |
| Acoustics, Idle (typical, measured in Idle 1 state) (dBA) |
28 |
28 |
| Acoustics, Seek (typical) (dBA) |
32 |
32 |
| Environmental/Shock |
| Shock, Operating 2ms (Read/Write) (Gs) |
30/30Gs |
30/30Gs |
| Shock, Nonoperating, 1ms and 2ms (Gs) |
200 |
200 |
| Physical |
| Height (mm/in) |
26.11mm/1.028in |
26.11mm/1.028in |
| Width (mm/in, max) |
101.85mm/4.01in |
101.85mm/4.01in |
| Depth (mm/in, max) |
146.99mm/5.787in |
146.99mm/5.787in |
| Weight (g/lb, typical) |
695g/1.531b |
695g/1.531b |
| Carton Unit Quantity |
20 |
20 |
| Cartons per Pallet/Cartons per Layer |
40/8 |
40/8 |
Key Advantages
Optimized for NAS with AgileArray™ AgileArray enables dual-plane balancing and timelimited error recovery for best-in-class RAID performance in multi-bay systems.
Always On, Always Accessible Designed for 24×7 use, allowing users to access their data any time, anywhere.
All-CMR Portfolio All IronWolf Pro drives utilize conventional magnetic recording (CMR) technology for consistent, best-in-class NAS performance.
Up to 30TB Broad range of capacity options to deliver scalable, cost-efficient storage solutions
Built Tough 550TB/yr workload allows commercial and enterprise NAS users to seamlessly store, share, and collaborate on large amounts of networked data.
Class-Leading Reliability and Dependability Rated for 2.5M hours MTBF and include a 5-year limited warranty for hassle-free data storage and best-in-class total cost of ownership.
Rotational vibration sensors. Built-in RV sensors for vibration tolerance and consistent performance in multi-bay systems.
IronWolf Health Management 1 IHM actively protects your NAS data with prevention, intervention, and recovery recommendations to ensure peak system health.
Peace of mind with Data Recovery 2 IronWolf Pro drives include 3 years of complimentary Rescue Data Recovery Services, where our in-house, secure facilities offer an industry-leading 95% recovery rate from accidental data corruption or drive damage
