Product Details:
|
Highlight: | Ddr4 Huawei Server 2288h V6,Huawei Server 2288h V6,2u Huawei Server 2288h V6 |
---|
Specification name
Specifications
Model
FusionServer 2288H V6
morphology
2U2-way rack server
processor
1/2 x 3rd Gen Intel ® Xeon ® Scalable processors (Ice Lake) (8300/6300/5300/4300 series), up to 270W, can support Montage processors
Chipset
Intel C621A
memory
16/32 DDR4 memory slots, up to 3200MT/s; Up to 16 Intel ® Optane ™ persistent memory 200 series, up to 3200MT/s
Local storage
It supports a variety of different hard disk configurations, and the hard disk supports hot swapping:
• Configurable with 8~31 x 2.5-inch SAS/SATA/SSD hard drives
• 12~20 x 3.5-inch SAS/SATA hard disks can be configured
• 4/8/16/24 NVMe SSDs can be configured
• Supports up to 45 x 2.5-inch HDDs, or 34 full NVMe SSDs
• Configurable with 2 M.2 SSD hard drives
RAID support
It can optionally support RAID 0, 1, 10, 5, 50, 6, 60, etc., support Cache supercapacitor protection, and provide RAID level migration, disk roaming, self-diagnosis, Web remote setting and other functions
Internet
Support multiple network expansion capabilities Support OCP 3.0 NIC -2 FLEX IO card slots support 2 OCP 3.0 NICs respectively, which can be selected on demand. Hot-swappable
PCIe extensions
14 PCIe 4.0 expansion slots for a wide range of applications
Heterogeneous accelerator cards
Supports 4 300W full-height full-length double-wide GPU accelerator cards, 11 half-height half-length single-width GPU accelerator cards, and 8 full-height full-length single-width GPU accelerator cards
fan
4 hot-swappable counter-rotating fans with N+1 redundancy
power supply
It can be configured with 2 redundant hot-swappable power supplies, supporting 1+1 redundancy, and the optional specifications are as follows:
• 900 W AC Platinum/Titanium power supply (input: 100 V AC~240 V AC or 192 V DC~288V DC)
• 1500W AC Platinum Power Supply
1000W (Input: 100V AC~127V AC)
1500W (Input: 200V AC~240V AC or 192V DC~288V DC)
• 1500W 380V HVDC power supply (input: 260V DC~400V DC)
• 1200W -48V ~-60V DC power supply (Input: -38.4V DC~-72V DC)
• 3000W AC Titanium power supply
2500W (Input: 200V AC~220V AC)
2900W (Input: 220V AC~230V AC)
3000W (Input: 230V AC~240V AC)
• 2000W
