802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller

Certification
China Beijing Qianxing Jietong Technology Co., Ltd. certification
China Beijing Qianxing Jietong Technology Co., Ltd. certification
Customer Reviews
The sales staff of Beijing Qianxing Jietong Technology Co.,Ltd are very professional and patient. They can provide quotations quickly. The quality and packaging of the products are also very good. Our cooperation is very smooth.

—— 《Festfing DV》LLC

When I was looking for intel CPU and Toshiba SSD urgently, Sandy from Beijing Qianxing Jietong Technology Co., Ltd gave me a lot of help and got me the products I needed quickly. I really appreciate her.

—— Kitty Yen

Sandy of Beijing Qianxing Jietong Technology Co.,Ltd is a very careful salesman, who can remind me of configuration errors in time when I buy a server. The engineers are also very professional and can quickly complete the testing process.

—— Strelkin Mikhail Vladimirovich

I'm Online Chat Now

802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller

802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller
802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller 802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller 802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller 802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller 802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller

Large Image :  802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller

Product Details:
Place of Origin: China
Brand Name: HUAWEI
Model Number: AirEngine 9700-M1 Access Controller
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $4200-5000 pcs Negotiable
Packaging Details: Carton Packaging
Delivery Time: 5-8 working days
Payment Terms: T/T
Supply Ability: 50/pcs/week

802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller

Description
Ports: 12 X GE + 12 X 10 GE + 2 X 40 GE (including 1 X 40 GE And 4 X 10 GE, Which Are Mutually Exclusive) Power Supply: 1 + 1 AC
Forwarding Capability: 120 Gbit/s (direct Forwarding) 120 Gbit/s (tunnel Forwarding) Maximum Number Of Managed APs: 2048
Maximum Number Of Access Users: 32,768 AP-AC Networking: Layer 2 Or Layer 3 Networking
High Light:

802.11 Ac Ap WLAN Device 9700-M1

,

802.11 WLAN Device 9700-M1

,

9700-M1 802.11 WLAN Device

Huawei AirEngine 9700-M1 Access Controller Manage Up To 2048 Access Points Series Of 802.11ax And 802.11ac APs

AirEngine 9700-M1 Access Controller



AirEngine 9700-M1 is a high-performance wireless Access Controller (AC) for medium- to large-sized enterprise campuses, enterprise branches, and school campuses. AirEngine 9700-M1 can manage up to 2048 Access Points (APs), providing up to 120 Gbit/s forwarding performance.

When used with Huawei's full series of 802.11ax and 802.11ac APs, AirEngine 9700-M1 delivers an adaptable solution for medium to large campus networks, enterprise office networks, wireless Metropolitan Area Networks (MANs), and hotspot coverage.



Superior Capacity and Performance

Supports 12 x GE ports, 12 x 10 GE ports, and 2 x 40 GE ports with 120 Gbit/s forwarding capability and management of 2048 APs.


Rich Functionality

Offers both direct forwarding and tunnel forwarding; fine-grained user rights management with user- and role-based access controls; and rich authentication mechanisms that minimize Wireless Local Area Network (WLAN) security threats.


Flexible O&M

Wide range of Operations and Maintenance (O&M) options, including eSight, web system, and Command Line Interface (CLI), all centrally managed with Huawei's intelligent eSight Network Management System (NMS).



Specifications

Parameters AirEngine 9700-M1
Ports 12 x GE + 12 x 10 GE + 2 x 40 GE (including 1 x 40 GE and 4 x 10 GE, which are mutually exclusive)
Power Supply 1 + 1 AC
Forwarding Capability 120 Gbit/s (direct forwarding)
120 Gbit/s (tunnel forwarding)
Maximum Number of Managed APs 2048
Maximum Number of Access Users 32,768
AP-AC Networking Layer 2 or Layer 3 networking
Forwarding Mode Direct forwarding (distributed forwarding or local forwarding) or tunnel forwarding (centralized forwarding)
AC Active/Standby Mode 1 + 1 HSB or N + 1 backup
Radio Protocols 802.11a/b/g/n/ac/ac Wave 2/ax



802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller 0

802.11 Ac Ap WLAN Device Huawei AirEngine 9700-M1 Access Controller 1

Notices:



1. Open the packaging, check the products carefully, and take them gently.

2. The product is a brand new original unopened equipment.

3. All products 1 year warranty, and the buyer is responsible for the return shipping cost.



International Buyers Please Note:
Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility.
Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying.
Customs fees are normally charged by the shipping company or collected when you pick the item up. These fees are not additional shipping charges.
We won't under-value merchandise or mark the item as a gift on customs forms. Doing that is against U.S. and international laws.
Customs delays are not the responsibility of the seller.
